Switchgear selection, made easier
Start with service voltage, continuous current, available fault current and installation environment. We help panel builders and electrical buyers narrow practical options before an inquiry reaches the engineering desk.
Confirm nominal voltage, frequency and grounding arrangement.
Compare interrupting rating with calculated available fault current.
Allow for continuous current, diversity, starts and future feeders.
Resolve enclosure, temperature, altitude and access constraints.
| Electrical duty | |
|---|---|
| Rated voltage and frequency | State system nominal values and any control-power requirements. |
| Rated current | Provide main bus and feeder currents with expected loading. |
| Interrupting capacity | Use the project fault-current study rather than a generic assumption. |
| Installation | |
| Enclosure and access | Indoor or outdoor location, ingress needs, front or rear access. |
| Documentation | One-line diagram, schedules, drawings and market-specific requirements. |
Discuss selective coordination, trip behavior and upstream/downstream device relationships.
Review footprint, cable entry, compartment access and maintenance clearance early.
Organize requested drawings, ratings and applicable series-level compliance evidence.
Translate engineering inputs into an inquiry that distributors can quote accurately.
We will help turn your operating conditions into a focused switchgear inquiry.
